The MICRONOVA J014 control unit is specific for wood and thermo-fired inserts at CANALIZED ARIA, consisting of a power card and a 7-segment led display board six digits through which you can view the various functions stove turned on, off or in stand by, temperature set in degrees celsius or fanheit, any alarms and operating tests.
Using the 4 buttons of the board you can turn on or off the control unit, select the type of operation (automatic or manual) in manual mode you can also increase or decrease the speed of the air fan, such functions can also be activated by the IR telecondo cod. 14710030 (optional)
The control unit can also be controlled by IR remote control
Very small size LxPxH 121x74x40 mm - attached to the wall in box 3 modules, comes with external plastic frame.
It has two analog inputs, including NTC 1 Kohm probe and a TRIAC output and a 5A SC relay output.
Mount on stoves CLAM - reference spare code CLAM 05021337 - Mod. Calorvision ECO 62 - Calorvision ECO 69 - Calorvision ECO 72 - Calorvision ECO 76 - Calorvision ECO 73 S.D. DX and SX - TOTEM ECO 62
Can mount on CAMINETTI CLAM models FAVILLA SERIE 3 and PRECEDENTI VERSIONS in exchange of the control unit Model 004 and CAMINETTI CLAM COMFORT in exchange of central Mod. 001 - reference spare code CLAM 05020052 -
WARNING! for the models FAVILLA SERIE 3 AND PRECEDENTS and COMFORT models replace the original probe on these fireplaces with a 1K NTC (see our codes 14708011 - 14708008 - 14708012) - carefully follow the wiring diagram and reset the parameters as shown in the downloadable manual by clicking here.
